500 Lb. Partially Stainless Steel Linear Actuated Elevating Cart – CART-500-LA-PSS – Vestil

SKU: CART-500-LA-PSS
$2,474.35
Estimated Lead Time:1-3 Days

The Vestil Model CART-500-LA-PSS provides precise, powered lifting for material handling applications where stainless construction and controlled positioning are critical. Unlike hydraulic carts, its electric linear actuator ensures accurate height adjustment with no drift.

This cart includes a 24V DC power system with two 12V batteries, onboard charger, and hand-held push-button pendant on a 6-ft coil cord. The stainless steel platform, handle, base frame, caster rigs, and hardware resist corrosion, while zinc-plated scissor legs and poly-on-steel casters ensure strength and long service life.
  • Model Number: CART-500-LA-PSS
  • Capacity: 500 lbs
  • Platform Size: 19.5" W × 32" L, stainless steel
  • Lift Range: 15" (min) to 33" (max), 27" travel
  • Overall Dimensions: 53.5" L × 44.5" W × 42" H
  • Frame Material: Stainless steel & zinc-plated legs
  • Power Source: Electric (cordless), 24V DC, includes on-board charger
  • Operation: Push button with pendant control (6 ft coil cord)
  • Casters: 4" dia., poly-on-steel (2 rigid, 2 swivel with brakes, 2" wide)
  • Weight: 185 lbs assembled
  • Finish: Silver

Manual (PDF)
Warranty (PDF)

Manufacturer Warranty: 1 Year (Limited – Parts)
