Steel Knockdown Vertical Cylinder Cabinet – 4 Cylinder Capacity – CYL-V-4-KD – Vestil

SKU: CYL-V-4-KD
$691.58
Estimated Lead Time:4-5 Weeks

The Vestil CYL-V-4-KD Steel Knockdown Vertical Cylinder Cabinet provides secure and compliant storage for up to four vertical gas cylinders. Built from heavy-duty 10-gauge steel, the cabinet features expanded steel mesh sides and door for ventilation and visibility, with a solid top, back, and bottom for durability. The hinged lockable door (padlock not included) and included securing chains protect cylinders in place, while lag holes in the base allow the unit to be anchored for additional safety. Finished in safety yellow with bold “FLAMMABLE – NO SMOKING” signage, this cabinet complies with OSHA 1910.110 (f)(6)(ii), NFPA 55/58, and CGA P-1 standards. Ships knocked down for reduced freight cost and requires user assembly.
  • Model Number: CYL-V-4-KD
  • Cylinder Capacity: 4 (vertical)
  • Weight Capacity: 200 lbs
  • Overall Dimensions: 30 in W × 32 in D × 35.25 in H
  • Assembled Weight: 125 lbs
  • Package Dimensions: 40 in W × 48 in D × 20 in H, 220 lbs
  • Material: 10-gauge steel
  • Finish: Safety yellow powder coat with red “FLAMMABLE – NO SMOKING” signage
  • Door Type: Hinged, lockable (padlock not included)
  • Construction: Expanded mesh sides/door; solid steel top, back, bottom
  • Features: Includes chains for securing cylinders; lag holes in base for anchoring
  • Compliance: OSHA 1910.110 (f)(6)(ii), NFPA 55/58, CSA B-149.2, CGA P-1
  • Assembly: Knockdown, requires user assembly

Warranty (PDF)

Manufacturer Warranty: 90 Days Limited – Parts
