Steel DC Powered Portable Hydraulic Drum Dumper – 72" Dump Height – 1,500 Lb. Capacity – HDD-72-15-P-DC – Vestil

SKU: HDD-72-15-P-DC
$5,808.95
Estimated Lead Time:6-8 Weeks

The Vestil Model HDD-72-15-P-DC Hydraulic Drum Dumper is engineered for handling heavy-duty drum dumping applications. With a 1,500 lb. weight capacity and a 72" maximum dump height, this DC-powered portable unit is built for efficiency, safety, and versatility. Compatible with 30- and 55-gallon steel, plastic, and fiber drums, it features a solid steel chute for controlled dumping.

The dumper includes an upper travel limit switch, an emergency brass safety velocity fuse, and adjustable vertical drum restraints to ensure maximum operator safety and drum stability. Mounted on casters with floor lock screws, the unit combines portability with secure operation. Its all-steel construction ensures durability and long service life in demanding industrial environment
  • Model Number: HDD-72-15-P-DC
  • Capacity: 1,500 lbs
  • Maximum Dump Height: 72 in.
  • Dump Angle: 45°
  • Accepted Drum Sizes: 30 & 55 Gallon
  • Accepted Drum Diameter Range: 16.5 – 23.5 in.
  • Accepted Drum Height Range: 27.5 – 39.5 in.
  • Overall Dimensions: 92"L x 36"W x 96"H
  • Level Height: 95.25 in.
  • Rotated Height: 157.5 in.
  • Handheld Control: 2-function pendant with 18–90 in. coil cord
  • Handle Height/Diameter: 38" / 1.25"
  • Power Source: 12V DC Lead Acid Battery (included)
  • Casters: (2) 6" x 2" Swivel & (2) 8" x 2" Rigid – Glass Filled Nylon
  • Assembled Weight: 961 lbs

User Manual (PDF)
Warranty (PDF)

Manufacturer Warranty: 1 Year Limited – Parts
